Enlarge led street light

led street light

Price: 5.0~10.0 USD
Payment Terms: T/T
Place of Origin: Guangdong, China (Mainland)
inquire
Add to My Favorites
HiSupplier Escrow
Share |

Product Detail

Model No.: KNSL-650-100W
Production Capacity: 20000 pcs/month
Delivery Date: 7-15days
Application: Highway
Lampshade Material: Toughened Glass
Input Voltage: AC85-265V or DC12V/DC24V
Freqency Range: 50-60Hz
Lamp's Efficiency: >91%
Junction Temperature: <80
Power Factor: >0.95
Means of Transport: Ocean
Packing: carton
Lighting Bulbs & Tube: Energy Saving
Power Supply: AC
Brand Name: KENA
Power: 20-200W
LED Luminous Efficiency: 60-100LM/W
Color Temperature: 2700-7000K
IP Grade: IP65
Size: 650*270*170mm

High Power LED Street Light
2. CE & RoHS approval
3.Die-casting aluminum casing
4.AC85-265V
5.70lm/w 80lm/w


High Power LED StreetsLighting
Specification of LED Street Light
  1. CE and RoHS approved.
  2. Die-casting aluminum casing  and high intensity toughened glass cover.
  3. High efficiency and power factor LED driver.
  4. Wide radiation angle, huge lighting area.
  5. Start without delay and flicker free.
  6. Good color rendering.
  7. Warm and cold color temperature are available.
  8. High shock & vibration resistant.
  9. Ideal heat dissipation design.
  10. No UV & IR, No Blinking and No Mercury & Lead free.
  11. Patented fixture design and Led package technology.
  12. Energy saving system, saving 50% energy than the conventional Metal halide lamp, Sodium Light or HPS light.
KNSL-650-100W led street light Main Technical Parameters
Input VoltageAC85V-265V
Luminance Uniformity
>0.5
Freqency Range 50Hz-60Hz Color Temperature WW2700K-3900K
Total Harmonic Distortion<9%  Color Temperature PW3900K-6000K
Power Factor   >0.9  Color Temperature WW     6000K-7000K
Power Efficiency>87%  Color Rendering Index WW Ra>68
Working Voltage DC30-36V  Color Rendering Index PW,CW Ra>75
LED Consumption 94W  LED Junction Temperature <80
System Consumption 107W Working Temperature-40-+55
LED Initial Flux WW 6450Lm  Storage Temperature -25-+65
LED Initial Flux PW 6550Lm  IP Grade IP65
LED Initial Flux CW 6500Lm  Working Life-Span 50000H
Lamp's Efficiency >90%  Power Line0.75mm2
Average Luminance
(Height 8M)
>50LUX  The color of the lamp shell White
Average Luminance
(Height 10M)
>30Lux  GW12kg
Average Luminance
(Height 12M)
>18Lux  NW10.5kg
Luminance Area
(Height 8M)
12*24M  Package Size(mm) 765*210*315
Luminance Area
(Height 10M)
16*32M  CertificateCE
Luminance Area
(Height 12M)
20*40M
Structure Size
